Product Details:
Place of Origin: China
Brand Name: Florescence
Certification: BV, CCS, ABS, LR etc.
Model Number: Florescence Ship Fender
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 200
Packaging Details: Metal and wooden pallet
Delivery Time: within 10 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 pcs per day

Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS

Description
Name: Cylindrial Rubber Fender Material: NR
Place Of Origin: Qingdao Certificate: BV, CCS, Etc.
Standard: ISO 9001 Part: Other
Colour: Black Size: Customized Size
High Light:

W Rubber Fenders

,

Tugboat W Rubber Fenders

,

Vertical Ship Rubber Fender



Product Introduction

Marine Rubber Fender also called rubber fender, marine fenders have become an ideal ship protection medium against collision among ship-to-ship (STS), ship to quay (STQ) and ship-to-berthing (STB), they are widely used for large tankers, vessels, docks, harbor wharfs and ocean platforms.

Classification Society Approved Florescence Ship Protecting Tugboat W Rubber Fenders

Tugboat W Rubber Fenders

 Fendering

Tug Fendering is supplied in a variety of styles and profiles to suit the large range of operational tugs, pusher barges and work boats. The most used profiles being.
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 0
Tugboat W Rubber Fenders Arrangement
• Cylindrical profile with chain recesses for bow and stern protection. • “W” style fender for applications that require a large curved hull area to be protected. • Block fender for hard wearing applications where replacement may be more frequent. • Square and “D” shaped profiles for side protection of vessels
The fendering is able to be supplied cut to length and drilled as required so that minimum onsite work is required. A wide variety of sizes are available in all the profiles shown. Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 1
Cylindrical Fender
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 2
Cylindrical Bow & Stern Fender
Cylindrical Bow & Stern Fenders are commonly used on ocean going tugs and where ignificant movement occurs between the tug and ship. This fender is commonly used in conjunction with Block or M-Fender to accommodate vessels with large bow flare such as container vessels.
Special features of the Cylindrical Bow and Stern Fender include tapered ends, protective end plates and groove to accommodate circumferential securing chains or straps. Single fender can be manufactured up to 800mm diameter and 13 metres in length (subject to transport limitations.) Longer fender sections can be made by joining shorter sections with joining plugs.
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 3
Curve Radius
Cylindrical Fenders are produce in straight lengths but can be pulled around radiused hull provided that the inside radius is at least four times the outside diameter of the fender.
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 4
ΦD
Φd
Amax
Bmax
C
ΦG
ΦJ
250
125
200
570
500
190
75
300
150
225
600
700
225
75
350
175
250
650
800
250
85
400
200
300
670
800
300
100
450
225
300
700
850
350
100
500
250
300
730
900
375
100
600
300
350
800
900
450
125
800
400
350
930
1000
600
125
900
450
350
1000
1100
675
150
1000
500
350
1060
1200
750
150
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 5
Extruded Fender

Extruded Fender

Extruded Fender is able to be delivered with fixing points, i.e. holes drilled into the fender, sloping ends, fixing plates, bolts and accessories. Extruded lengths vary dependant on handling and transport criteria. Extruded fenders are normally used as side fendering on tugs, supply vessels and pilot boats.
Typical Mounting Details For Ships
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 6
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 7
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 8
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 9
Ship Protecting Tugboat W Rubber Fenders Vertical Used For STS 10
