Product Details:
|
| Material: | Natural Rubber:RSS3,imported From Thailand | Cord Fabric: | 1880D2,100% Raw Silk |
|---|---|---|---|
| Thickness: | More Than 5.5mm | Pressure: | 0.17-0.33Mpa |
| Color: | Black | Layer: | 3-12 Layers |
| High Light: | inflatable lift bags,boat lift air bags,RSS3 Ship Launching Airbags |
||
High Strength And Air Tightness Of Marine And Boat Inflatable Rubber Airbag
Storage of the inflatable rubber airbag
* If the air bag will not used for quite a long time, it shall be washed and dried, filled with French chalk inside and coated with French chalk outside as well as put in dry, shady and ventilated place in the room.
* Place storing the air bag shall be far away from the heat source.
* The air bag can’t contact with acid, alkali, grease and organic solvents.
* The air bag should be stretched flat when not used. it’s not allowed to pole up and stack heavy object on the air bag.
Special attentions during the use of the airbag
* Control the working pressure strictly and it’s not allowed to exceed the working pressure.
* There shall be no sharp and protruding hard object on the contact surface with the airbag in case it punctures the skin of the airbag .
* Try to avoid distortion happened to the length direction of the airbag
* Empty charge test shall be performed if the air bag is not used for a long time or reused after repair. Charge pressure if the airbag shall be the same as the test pressure valve when delivered. Inspectors shall be at least 3 meters away from the air bag. For air bag recovered from large damage, its working pressure shall be reduced reasonably. Besides, annual check shall be conducted on air bag which are used often.
* Do not drag the air bag on the ground.
Quality guarantee
The product is up to the quality requirements of ISO14409:2011 “Air bags for the up-to-slipway and launching of the ship.
Should quality problem happen within a year, it is guaranteed to change or refund on the condition that the transportation, storage and working conditions are up to the regulations.
Working pressure of Florescence marine rubber airbag:
| Diameter | Layer | Work pressure | Diameter | Layer | Work pressure |
| D=0.8M | 3 | 0.13 Mpa | D=1.5M | 3 | 0.07 Mpa |
| 4 | 0.17 Mpa | 4 | 0.09 Mpa | ||
| 5 | 0.21 Mpa | 5 | 0.11 Mpa | ||
| 6 | 0.25 Mpa | 6 | 0.13 Mpa | ||
| 7 | 0.30 Mpa | 7 | 0.15 Mpa | ||
| 8 | 0.33 Mpa | 8 | 0.18 Mpa | ||
| D=1.0M | 3 | 0.10 Mpa | D=1.8M | 3 | 0.06 Mpa |
| 4 | 0.13 Mpa | 4 | 0.08 Mpa | ||
| 5 | 0.17 Mpa | 5 | 0.09 Mpa | ||
| 6 | 0.20 Mpa | 6 | 0.11 Mpa | ||
| 7 | 0.25 Mpa | 7 | 0.13 Mpa | ||
| 8 | 0.28 Mpa | 8 | 0.15 Mpa | ||
| D=1.2M | 3 | 0.09 Mpa | D=2.0M | 3 | 0.05 Mpa |
| 4 | 0.11 Mpa | 4 | 0.07 Mpa | ||
| 5 | 0.14 Mpa | 5 | 0.08 Mpa | ||
| 6 | 0.17 Mpa | 6 | 0.10 Mpa | ||
| 7 | 0.20 Mpa | 7 | 0.12 Mpa | ||
| 8 | 0.23 Mpa | 8 | 0.14 Mpa |
Our service
Pre-sale service:Every product will be inspected before shipment,guarantee the quality
On-sale service:Choose suitable package and transportation,gurantee the goods reach to customers safely,save freight for customers
After-sale service:One-to-one VIP service
We solemn promise:
1) Contact with customers statedly
2) Guide the installation and using of products
3) Provide maintenance manual of related products
4) Provide mending material for products
