Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier

Certification
China Qingdao Florescence Marine Supply Co., LTD. certification
China Qingdao Florescence Marine Supply Co., LTD. certification
I'm Online Chat Now

Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier

Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier
Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier

Large Image :  Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier

Product Details:
Place of Origin: Shandong, China
Brand Name: Qingdao Florescence
Certification: ISO, etc
Model Number: RY- Roller Barrier
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiated
Packaging Details: As clients need
Delivery Time: To be negotiated
Payment Terms: T/T, L/C, D/A, D/P,etc
Supply Ability: 300 Piece/Pieces per Week

Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier

Description
Product Name: Roller Barrier Material: EVA,PE,etc
Size: 350*250mm,350*490mm,request Color: Yellow, Orange Or As Your Request
Type: Double Beams Or Single Beam Distance: 700mm Or 1000mm
Application: Highway, Curved Ramp, Tunnel Entrance,etc Service Life: 10 Years
Warranty: 1 Year
High Light:

Safety Roller Crash Barrier

,

EVA Safety Roller Crash Barrier

,

Rolling Type Crash Barrier

Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier

Products specification
Roller (royalty barrel)
H240xφ345mm, H240xφ350
Post
φ140x2200x4.5mm
Cross beam
100x80x4.0mm
Connecting rack
430x84x70x4.0mm
U shape frame
380x70x6.0mm
Turning circle
φ182xφ145x2.0mm
Square buckle
46x64x4.0mm
Terminal
1300x230x2.0mm
Bolts&Nuts
M20x60/120/140mm



Roller EVA material with elastic characteristics is used as raw material, which can slow down the lateral impact process of the out-of-control vehicle.

Moreover, the rotating barrel can rotate around the column under a certain impact, driving the out-of-control vehicle to return to the correct driving direction.

Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier 0

Safety Roller Barrier
While externally the Safety Roller Crash Barrier is a highly visual crash deterrent that alerts drivers, it’s the technology
behind its design and construction that has seen it awarded the world’s first MASH TL4 accreditation judged on:
Structural Adequacy
Occupant Risk
Vehicle Trajectory Post Impact

Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier 1

The Safety Roller Crash Barrier is a barrier system ingeniously engineered to prevent fatal injuries by firstly
absorbing shock energy and subsequently converting that shock energy into rotational energy.
The key to its effectiveness is the energy from an impact being absorbed and then deflected into the barrier and converted into rotational energy along the barrier.
This key lifesaving feature has enabled the barrier to perform exceptionally well in the stringent MASH testing, which
additionally delivers its ability to survive moderate impacts and consequently require little or no repair or replacement.
The superior performance has been achieved because of its advanced design elements:
·Roller absorbs initial collision shock, which converts to rotational energy
·Front rails absorb second shock

Safe Rolling Type Safety EVA Roller Barrier Safety Roller Crash Barrier 2
·Back rails absorb third shock

·Metal pipe inserted between the rails to strengthen the post
·Frictional rotating stopper boards installed to the top and bottom of the rollers act as clutch plates to decrease speed
