ISO9001:2015 Solid Rubber Fender Supper Cell Fender

Large Image : ISO9001:2015 Solid Rubber Fender Supper Cell Fender

Product Details:

Place of Origin:	China
Brand Name:	Florescence
Certification:	BV, CCS, ABS, LR etc.
Model Number:	Supper Cell Fender

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	200
Packaging Details:	Metal and wooden pallet
Delivery Time:	within 10 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	200 pcs per day

Contact Now

ISO9001:2015 Solid Rubber Fender Supper Cell Fender

Description

Part:	Supper Cell Fender	Color:	Black
Material:	Rubber	Application:	Ship And Dock Protecting
Diameter:	As The Drawing	Product Name:	Dock Fender
Size:	As Client Drawing	Standard:	Pianc 2002
High Light:	ISO9001 Solid Rubber Fender , Dock Solid Rubber Fender , Solid Rubber Marine Dock Fender

ISO9001:2015 factory made solid rubber fender Supper Cell Fender Manufacturer

Product Description

Supper Cell Fender

Florescence Marine Systems is a leader in the design and manufacture of advanced marine fender systems. We provide best practice design and quality materials ensure a long, low maintenance service life, no matter how demanding the working and environmental conditions. All fenders are supplied fully tested and meet PIANC 2002 guidelines. Our pneumatic fenders are also completely ISO 17357-1:2014 compliant. Take a approach to fender performance with Florescence.

DESIGN

Our team generates 3D CAD designs, application-engineering drawings, a bill of materials, finite engineering analyses and calculations for both our fender systems and marine technology solutions.

Manufacture

Our entire product range is manufactured in-house, meaning we have full control over the design and quality of everything we produce. Our strategically located, stateof-the-art facilities ensure our global, industry leading manufacturing capability.

TESTIN

Across our entire product range, stringent testing comes as standard at every step in our in-house manufacturing process. We ensure that life-cycle and performance of our entire product range meets your specifications, and more.

Installation

Dedicated project management, from solution design right the way through to on-site installation support. We design products and solutions that always consider ease of installation and future maintenance requirements.

Support

We provide 12 month gurantee. And this service doesn’t stop after a product is installed. You have our full support throughout the entire lifetime of your project, including customized training programs, maintenance and on-site service and support.

Supper Cone Fender

Super cone rubber fender is the 3rd generation product of cell type fender; Cone fenders have the highest energy to reaction ratios of any fender currently in use; Match up with frontal panel and low friction PE pad; Suitable for all kinds of wharf.

Type	Specification
Type	H	ΦU	ΦS	ΦP	ΦD	Holes	n-Ma	n-Φd	h
FCO500	500	425	325	675	750	4	M24	30	25
FCO600	600	510	390	810	900	6	M24	30	27
FCO700	700	595	455	945	1050	6	M30	38	32
FCO800	800	680	520	1080	1200	6	M36	44	36
FCO900	900	765	585	1215	1350	6	M36	44	41
FCO1000	1000	850	650	1350	1500	6	M42	56	45
FCO1100	1100	935	715	1485	1650	6	M42	50	50
FCO1150	1150	998	750	1550	1725	6	M42	56	52
FCO1200	1200	1020	780	1620	1800	8	M42	50	54
FCO1300	1300	1105	845	1755	1950	8	M48	60	59
FCO1400	1400	1190	930	1890	2100	8	M48	60	66
FCO1600	1600	1360	1060	2160	2400	8	M48	70	72
FCO1800	1800	1530	1190	2430	2700	10	M56	76	78
REMARK: Different sizes of FLSC type rubber fender can be made according to customers' request.

Supper Cell Fender

Provide good energy capability, high deflection; Match up with frontal panel and low friction PE pad; Strong and well designed; Low hull pressure, reduced shear force; Suitable for a wide range of berthing applications.

Type	Specification
Type	H	ΦD1	ΦD2	h	holes	n-ΦD
FLSC400H	400	550	650	25	4	φ30
FLSC500H	500	550	650	25	4	φ32
FLSC630H	630	700	840	30	4	φ39
FLSC800H	800	900	1050	30	6	φ40
FLSC1000H	1000	1100	1300	35	6	φ47
FLSC1150H	1150	1300	1500	40	6	φ50
FLSC1250H	1250	1450	1650	45	6	φ53
FLSC1450H	1450	1650	1850	47	6	φ61
FLSC1600H	1600	1800	2000	50	8	φ61
FLSC1700H	1700	1900	2100	55	8	φ66
FLSC2000H	2000	2000	2200	55	8	φ74
FLSC2250H	2250	2300	2550	60	10	φ74
FLSC2500H	2500	2700	2950	70	10	φ90
FLSC3000H	3000	3150	3350	75	12	φ90
REMARK: Different sizes of FLSC type rubber fender can be made according to customers' request.

Supper Arch Fender

The super arch fender is modified from the traditional V type arch fender. High energy absorption and low reaction force. Strong and hard wearing, Excellent shear performance, Large range of standard sizes. Can be fitted with either U HMW-PE face pad. connected to a steel panel, reduce the friction factor.

Sepcification	Diamension(mm)
Sepcification	H	L	L1	C	Q	B	B1	B2	B3
FLA 150×1000	150	1000	1075	110	855	98	240	300	96
FLA 150×1500	150	1500	1575	112. 5	675	98	240	300	96
FLA 150×2000	150	2000	2075	215	620	98	240	300	96
FLA 150 ×2500	150	2500	2575	220	785	98	240	300	96
FLA 150×3000	150	3000	3075	215	715	98	240	300	96
FLA 150 ×3500	150	3500	3575	220	671	98	240	300	96
FLA 200 ×1000	200	1000	1100	120	860	145	320	400	128
FLA 200 ×1500	200	1500	1600	120	680	145	320	400	128
FLA 200 ×2000	200	2000	2100	120	620	145	320	400	128
FLA 200 ×2500	200	2500	2600	122. 5	785	145	320	400	128
FLA 200 ×3000	200	3000	3100	120	715	145	320	400	128
FLA 200 ×3500	200	3500	3600	120	672	145	320	400	128
FLA 250 ×1000	250	1000	1125	130	865	164	410	500	160
FLA 250 ×1500	250	1500	1625	132. 5	680	164	410	500	160
FLA 250 ×2000	250	2000	2125	132.5	620	164	410	500	160
FLA 250 ×2500	250	2500	2625	127. 5	790	164	410	500	160
FLA 250 ×3000	250	3000	3125	132.5	715	164	410	500	160
FLA 250 ×3500	250	3500	3625	130	673	164	410	500	160
FLA 300 ×1000	300	1000	1150	140	870	225	490	600	195
FLA 300 ×1500	300	1500	1650	140	685	225	490	600	195
FLA 300 ×2000	300	2000	2150	137.5	625	225	490	600	195
FLA 300 ×2500	300	2500	2650	140	790	225	490	600	195
FLA 300 ×3000	300	3000	3150	145	715	225	490	600	195
FLA 300 ×3500	300	3500	3650	140	674	225	490	600	195
FLA 400 ×1000	400	1000	1200	150	900	300	670	800	260
FLA 400 ×1500	400	1500	1700	150	700	300	670	800	260
FLA 400 ×2000	400	2000	2200	147.5	635	300	670	800	260
FLA 400 ×2500	400	2500	2700	150	800	300	670	800	260
FLA 400 ×3000	400	3000	3200	150	725	300	670	800	260
FLA 400 ×3500	400	3500	3700	150	680	300	670	800	260
FLA 500 ×1000	500	1000	1250	160	930	375	840	1000	325
FLA 500 ×1500	500	1500	1750	160	715	375	840	1000	325
FLA 500 ×2000	500	2000	2250	157.5	645	375	840	1000	325
FLA 500 ×2500	500	2500	2750	160	810	375	840	1000	325
FLA 500 ×3000	500	3000	3250	165	730	375	840	1000	325
FLA 500 ×3500	500	3500	3750	160	686	375	840	1000	325
FLA 600 ×1000	600	1000	1300	170	960	450	1010	1200	390
FLA 600 ×1500	600	1500	1800	170	730	450	1010	1200	390
FLA 600 ×2000	600	2000	2300	167.5	655	450	1010	1200	390
FLA 600 ×2500	600	2500	3800	170	820	450	1010	1200	390
FLA 600 ×3000	600	3000	3300	170	740	450	1010	1200	390
FLA 600 ×3500	600	3500	3800	170	692	450	1010	1200	390
FLA 800 ×1000	800	1000	1400	180	1040	600	1340	1600	520
FLA 800 ×1500	800	1500	1900	180	770	600	1340	1600	520
FLA 800 ×2000	800	2000	2400	180	680	600	1340	1600	520
FLA 800 ×2500	800	2500	2900	182. 5	845	600	1340	1600	520
FLA 800 ×3000	800	3000	3400	180	760	600	1340	1600	520
FLA 1000 ×1000	1000	1000	1500	200	1100	750	1680	2000	650
FLA 1000 ×1500	1000	1500	2000	200	800	750	1680	2000	650
FLA 1000 ×2000	1000	2000	2500	200	700	750	1680	2000	650
