Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T

Certification
China Qingdao Florescence Marine Supply Co., LTD. certification
China Qingdao Florescence Marine Supply Co., LTD. certification
I'm Online Chat Now

Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T

Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T
Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T

Large Image :  Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T

Product Details:
Place of Origin: Shandong,China
Brand Name: Florescence RUBBER
Certification: CCS,ABS,DNV,LR,ISO9001
Model Number: Florescence rubber fender(159)
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: nude,container
Delivery Time: 5-10 work days
Payment Terms: Western Union, L/C, T/T
Supply Ability: 100 pcs/month

Easy Installation Large Pneumatic Rubber Fenders For Boat Weight 15000 - 200000T

Description
Size: Customized.diameter From 0.3-4.5m Warranty Period: 24 Months
Certificates: CCS,ABS,DNV,BV,LR Design Using Life: More Than 10 Years
Color: Black , Grey , White Standard: ISO17357
High Light:

boat dock fenders

,

inflatable marine fenders

,

Large Boat Pneumatic Rubber Fenders

Suitable For Boat Weight From 15000-200000 t Of Pneumatic Marine Rubber Fender

Application of rubber fender:
* pneumatic rubber fender has widespread application as following:
* Ship to ship,ship to wharf
* Oil tankers, container vessels
* Luxury yachts, ocean platforms
* Larges shipyards
* Fender system
* Military ports ,warship
* Larger under water foundations of bridges, etc.


Advantages of marine rubber fender:
* Absorb more energy,less reverse impact on the ships
* More flexible ,easy installation
* Long term service life
* Not being bent out of shape under pressure
* Many different sizes and shape available
* Pass CCS,DNV,ABS
* Durable, practical and economical

Technical performance of marine rubber fender

Specification
DXL(m)

0.05Mpa(Initial pressure 0.05Mpa)(Initial pressure 0.08Mpa)
Weight(kg)Reaction force(KN)

GEA
(KJ)

Weight
(kg)

Reaction force(KN)

GEA
(KJ)

0.5X1.025674625858
0.6X1.032748329811
0.7X1.550137175018024
1.0X1.580182328023945
1.0X2.01002574512533863
1.2X2.01202976316539088
1.35X2.5165427102226561142
1.5X3.0315579153370761214
1.7X3.0405639191436840287
2.0X3.55908753086321150430
2.5X4.01050138166311101815925
2.5X5.513332019943141026531317
3.0X5.0188020001050215527091571
3.0X6.0216024881312247032921888
3.3X4.5202018841175230024761640
3.3X6.0230027831675260036522338
3.3X6.5270030151814308039612532
3.3X10.6440352573067502069074281
4.5X9.0655457474752747075516633
4.5X128739798464739960104909037
Note:The weight is the fender body weight(without tires and chain),with weight error of ±10% and counterforce error of ±10%


Notes about marine rubber fender

* Frequently check whether the fender body si damaged and whether the pressure is normal,and the valve core must be replaced every six moths

* The steel wire should wrap the rubber pipe,when trying steel wire to pneumatic rubber fender in case the fender is stabbed

* The surface or subject next to the pneumatic rubber fender can’t be hard and sharp-pointed in case the pneumatic rubber fender is stabbed

* The accessories and jip’s nuts can’t be loose when testing the internal pressure

* The rope net should be reliable,the steel wire used for hanging metal parts and the hook link can’t be tied in disorder.
