|Material:||Foam,EVA||Color:||Black,Orange, Grey, Blue|
|Name:||Foam Filled Fender||Diameter:||0.3-4.5m|
|Length:||1-9m||Application:||Yacht, Ship, Port|
Mooring Fishing Marine Boat Fender,
Foam Filled Marine Boat Fender
|*Style||Foam Filled Marine Fender|
|*Material Type||Foam, Polyurethane|
|*Dimension information||Diameter*Length (0.3*0.5-3.5*7.0)M|
The use of memory foams for the fender core, which have high compressive strengths, results in an ability to absorb a great deal of energy during marine operations. This is complemented by low reaction forces, making berthing operations easier – especially in difficult conditions. Users also gain peace of mind from knowing that the closed cell structure of the foams used means that these fenders are virtually unsinkable and will keep functioning – even if damaged beyond viable repair.
Foam Filled Fenders’ parameters are available in diameters from 300 mm to 4,500 mm and lengths from 800 mm to 10,600 mm, Depends on the different used and applications,the fenders could be installed with a two or four point mounting system. Standard colors of foam filled fenders are black and orange, if any special requests from our customers we are willing to offer personal options for colors.
Our floating foam fenders also have a simple yet unique internal structure, which allows the shear loads to be absorbed by a through-chain arrangement terminating in end-shackles rather than the body of the fender itself. This has been engineered so that in the event of overload, any damaged components of this system can be replaced in isolation – as opposed to other foam fenders where the end-fittings form an integral part of the internal workings of the fender and which, if damaged by shear forces, can lead to the fender being written off.
Foam Fenders Constructions
Foam fenders are constructed of three parts providing an important function in the construction. The outside closed-cell
polyethylene foam core absorbs the impact from severe operating conditions, while the inside skin of reinforced polyuretane
elastomer resists wear and tear among austere condition.
Features of Foam Filled Fender
·Great Floating Performance, not influenced by tidal waves ·Bright Colours are available upon customer request (not all) ·No air inflation needed (as compared to pneumatic fenders) ·High Energy Absorption ·Reasonably resistant to acid and alkali ·Good Angular Performance ·Strong & safe ·Extremely long useful life
actory established in 1992, Qingdao Florescence Marine Supply Co., Ltd (Subsidiary of Qingdao Florescence Co., Ltd) specializes in manufacturing pneumatic rubber fenders, foam fenders, various ship dock rubber fenders, and ship launching & salvage rubber airbags.
FLORESCENCE products are designed, manufactured, and tested by per ISO 9001:2015 requirements. And every unit is robustly built to the stringent requirements of ship surveyors such as CCS, BV, RS, ABS, LR, etc.
We are the supplier of many navy, such as Bangladesh Navy, France Navy, Greece Navy, Thailand Navy, Italy Navy, Philippines Navy, etc.
FLORESCENCE considers our clients as a part of the team, treating them as partners. We are always together with them on each step of the way, from finding the solutions of fender using and ship launching to the manufacturing and installation operations on site. Our rich experience has earned us a reputation as a dependable partner in many ports and shipyards around the world.
EVA fender is the perfect solution for storm conditions, having the potential to outperform pneumatic units during severe weather.
Foam Filled Fenders are versatile, robust and suitable for almost all applications. The manufacturing process allows for virtually
any size of fender to be constructed and selecting the appropriate grade of foam core and elastomeric skin means the performance
of a fender can be precisely gauged to meet specific specification requirements.Characteristically Foam Filled Fenders have a high
energy absorption compared to their reactive load meaning they are ideal for existing structures and certain hull types such as catamarans and cruise ships.
Difference Between EVA Fenders&PVC Fenders
|Difference||EVA fenders||PVC fenders|
EVAfoamcore+ Nylon Cord
Fabrics+Polyurea Spraying Coating
|Polyvinyl Chloride PVC +air inside|
|2Service life||8-10 years||2-3 years|
|2Feature||Solid, unsinkable,Ultra-tough||Hollow, easy to be ruptured|
High Energy absorbing,Low Reaction,
Low hull pressures (just 172kN/m2)
|Not as good as EVA fenders|
Because of unsinkable design,
they can provide constant
protection for ships
Because of easiness of rupturing,
put ships in danger of collision
Even at the end of their first service
life they can be returned to the
factory for refurbishment before
going back to work
|Once broken stop working|
Construction of Florescence Foam Filled Fender
Our Foam Filled Fenders are constructed of three parts each providing an important function in the construction and lifespan of the fender. The
three parts are (1) The closed cell EVA foam. (2) Outer rubber + nylon cord fabrics. (3) Polyurea spraying coat.
The closed cell EVA foam core used inside offers un-sink ability during operation.
Outer Rubber + Nylon Cord Fabrics
The outer rubber + nylon cord fabrics is specifically designed to seal EVA foam inside and to prevent any leakage.
Polyurea Spraying Coating
Polyurea coating is permanent spray on coatings that protect the surface of fender body. It is more durable than rubberand flexible in all weather conditions; no softening in heat or becoming brittle in cold. Dent, scratch and chemical resistant
Key Attributes :
High energy absorption and low reaction force
Conforms to hull protrusions
Ultra-tough, unsinkable design
Remains fully functional even if skin is punctured
500mm diameter to 4500mm diameter in 1000mm length to 12000mm length based on type and application.
Custom sizes can also be manufactured.
RoRo and ferries
Oil and gas tankers
Quality Control of Raw Materials
The EVA foam we use in the construction of our Foam Filled Fenders is the closed cell type. It is made from Ethylene Vinyl Acetate and blended
copolymers. It has a high level of chemical cross linking. These foams are flexible and resilient making them ideal for fendering products. Importantly,
the foams are also chemically inert and nonabsorbentmaking them suitable for use in marine environments.
